Automotive Relay SPST-NO (1 Form A) 12V 45A 90 Ohm Through Hole

Specifications

  • Series: V23076
  • Coil Type: Non Latching
  • Coil Current: 133 mA
  • Coil Voltage: 12 VDC
  • Contact Form: SPST-NO (1 Form A)
  • Contact Rating: 45 A
  • Switching Voltage: 12 VDC - Nominal
  • Must Operate Voltage: 6.9 VDC
  • Must Release Voltage: 1.2 VDC
  • Operate Time: 5 ms
  • Release Time: 3 ms
  • Features: Fully Sealed
  • Mounting Type: Through Hole
  • Termination Style: PC Pin
  • Operating Temperature: -40°C to 85°C
  • Contact Material: Silver Nickel
  • Coil Power: 1.6 W
  • Coil Resistance: 90 Ohms
Underside of relay

Product Identification

Product Type:Automotive Relay

Features

Pins:4
Coil Voltage:12 VDC
Coil Resistance:90 Ohm
Contact Form:SPST-NO
Current Rating:45 A
,
