AC to DC Switching Power Supply Single Output with PFC Function 5 Volts 15 Amps 75 Watts

5 Volts @ 15 Amps

Specifications

  • Output Power (W): 75
  • Size (L x W x H) inches: 6.26 X 3.82 X 1.18
  • Ripple & Noise (mV p-p): 80
  • Load Regulation (±): 0.5%
  • Line Regulation (±): 1%
  • Efficiency: 82%
  • Agency Approvals: CE/CUL/TUV/CCC/CB/CE
  • Universal AC input / Full range
  • Built in PFC function
  • Protections: short circuit, over voltage, overload
  • Cooling by free air convention
  • Built in constant current limiting circuit
  • 1U low profile enclosure (30 mm)
  • Remote ON-OFF control
  • LED indicator for power on
  • 100% full load burn in test
  • 3 year warranty

Overview

Product Identification

Type:Auto Switching SMPS
Manufacturer Series:RSP-75

Compliance

Agency Approvals: CB, CCC, CE, CUL, EAC, EN, TUV, UL

Dimensions & Appearance

Style:Enclosed
Color:Silver
Height:1.18 in.
Width:3.82 in.
Length:6.26 in.

Operating conditions

Minimum Operating Temperature:-25°C
Maximum Operating Temperature:70°C

Input

Input Frequency:47 Hz to 63 Hz
Input Voltage:85 VAC to 264 VAC
Maximum Input Current:0.9 A

Output

Number of Outputs:1
Output Voltage (Channel 1):5 VDC
Output Voltage:5 VDC
Output Connector Type:Screw Terminal Block
Output Current (Channel 1):15 A
Output Current:15 A

Features

PFC Function:Yes
Minimum Isolation Voltage:3750V
Efficiency:82%
Power Rating:75 W
,
