AC to DC Switching Power Supply Single Output with PFC Function 48 Volts 1.36 Amps 65.3 Watts - Model B

48 Volts @ 1.36 Amps

Specifications

  • Output Power (W): 65.3
  • Size (L x W x H) inches: 7.45 X 2.42 X 1.45
  • Ripple & Noise (mV p-p): 300
  • Line Regulation (±): 0.5%
  • Load Regulation (±): 0.5%
  • Efficiency: 90%
  • Cooling by free air convection
  • Built in PFC function
  • Constant current design
  • Protections: short circuit, over temperature, over current, over voltage
  • Class II power unit
  • Three in one dimming function
  • Meets 4KV surge immunity level (EN61000-4-5)
  • OCP point adjustable through output cable
  • IP67 rated
  • Agency Approvals: UL/CUL/ENEC/CB/FCC/CE
  • 5 year warranty

Product Identification

Product Type:Auto Switching SMPS
Manufacturer Series:HVG-65

Compliance

Agency Approvals: CUL, EAC, EN, FCC, UL

Dimensions & Appearance

Style:Enclosed
Color:Silver
Height:1.45 in.
Width:2.42 in.
Length:7.44 in.

Operating conditions

Minimum Operating Temperature:-40°C
Maximum Operating Temperature:70°C

Input

Input Frequency:47 Hz to 63 Hz
Maximum Input Current:0.22 A
Input Voltage:180 VAC to 528 VAC

Output

Number of Outputs:1
Output Connector Type:Stripped and Tinned
Output Voltage:48 VDC
Output Current:1.36 A
Output Range:N/A

Features

PFC Function:Yes
Minimum Isolation Voltage:3750V
IP Rating:IP67
Efficiency:90%
Power Rating:65.3 W
,
