AC to DC Switching LED Power Supply with PFC Function 48V 1.88A 90W

48 Volts @ 1.88 Amps

Specifications

  • Output Power (W): 90
  • Size (Dia x H) inches: 6.73 X 2.48 X 1.48
  • Efficiency: 90.5%
  • Agency Approvals: UL/CUL
  • Universal AC input / Full range up to 305 VAC
  • Built in active PFC function
  • IP67 rated
  • Protections: short circuit, over voltage, over temperature, over load
  • Constant voltage PWM style output
  • Built in 2 in 1 dimming function (0~10Vdc or PWM signal)
  • Dimming range : 0~100%
  • Class II power unit, no FG
  • No load power consumption <0.5W
  • Suitable for dry, damp, and wet locations
  • 5 year warranty

Product Identification

Product Type:Auto Switching SMPS
Manufacturer Series:PWM-90

Compliance

Agency Approvals: CB, CCC, CE, CUL, EAC, EN, ENEC, UL

Dimensions & Appearance

Style:Enclosed
Color:Black
Height:1.48 in.
Width:2.48 in.
Length:6.73 in.

Operating conditions

Minimum Operating Temperature:-40°C
Maximum Operating Temperature:70°C

Input

Input Frequency:47 Hz to 63 Hz
Input Voltage:90 VAC to 305 VAC
Maximum Input Current:0.95 A

Output

Number of Outputs:1
Output Connector Type:Stripped and Tinned
Output Voltage:48 VDC
Output Current:1.88 A
Output Range:N/A

Features

PFC Function:Yes
Minimum Isolation Voltage:3750V
IP Rating:IP67
Efficiency:90.5%
Power Rating:90.24 W
,
