AC to DC Switching LED Power Supply Single Output with PFC Function 42-72 Volts 0.35 Amps 25.2 Watts

42 to 72 Volts @ 0.35 Amps

Specifications

  • Output Power (W): 25.2
  • Size (L x W x H) inches: 5.7 X 1.5 X 0.9
  • Ripple & Noise (mV p-p): 7.2
  • Efficiency: 87%
  • Agency Approvals: UL/CB/CE/TUV
  • Universal AC input / Full range
  • Built in active PFC function
  • Fully isolated plastic case
  • Cooling by free air convection
  • Protections: short circuit
  • Class II power unit, no FG
  • No load power consumption <0.5W
  • 100% full load burn in test
  • High reliability
  • Non-Class 2
  • Warranty: 2 years

Product Identification

Product Type:Auto Switching SMPS
Manufacturer Series:PLM-25

Compliance

Agency Approvals: CB, CE, CUL, EAC, EN, ENEC, UL, UL, CUL, CB, CE, EN, ENEC, EAC

Dimensions & Appearance

Style:Enclosed
Color:White
Height:0.86 in.
Width:1.49 in.
Length:5.7 in.

Operating conditions

Minimum Operating Temperature:-30°C
Maximum Operating Temperature:45°C

Input

Input Frequency:47 Hz to 63 Hz
Maximum Input Current:0.15 A
Input Voltage:110 VAC to 295 VAC

Output

Number of Outputs:1
Output Connector Type:Screw Terminal Block
Output Current:0.35 A
Output Voltage:See Output Range
Output Range:42 VDC to 72 VDC

Features

PFC Function:Yes
IP Rating:IP30
Minimum Isolation Voltage:3750V
Efficiency:87%
Power Rating:25.2 W
,
