AC to DC Switching LED Power Supply Single Output with PFC Function 20 Volts 4.5 Amps 90 Watts

20 Volts @ 4.5 Amps

Specifications

  • Output Power (W): 90
  • Size (Dia x H) inches: 6.73 X 2.48 X 1.48
  • Ripple & Noise (mV p-p): 150
  • Line Regulation (±): 0.5%
  • Load Regulation (±): 0.5%
  • Efficiency 115 VAC: 89%
  • Efficiency 230 VAC: 90%
  • Frequency Range: 47~63Hz
  • Agency Approvals: UL/CUL
  • Universal AC input / Full range
  • Built in active PFC function
  • IP67 rated
  • Protections: short circuit, over voltage, over temperature, over current
  • Cooling by free air convection
  • NRCac compliant
  • Meets EISA 2007 standard (Energy Independence and Security Act)
  • Class II power unit, no FG
  • 4 pin DIN plug
  • No load power consumption <0.15W
  • Suitable for dry, damp, and wet locations
  • 5 year warranty

Product Identification

Type:Auto Switching SMPS
Manufacturer Series:OWA-90

Compliance

Agency Approvals: FCC, CUL

Dimensions & Appearance

Style:Desktop
Color:Black
Height:1.48 in.
Width:2.48 in.
Length:6.73 in.

Operating conditions

Minimum Operating Temperature:-40°C
Maximum Operating Temperature:70°C

Input

Input Frequency:47 Hz to 63 Hz
Input Voltage:90 VAC to 264 VAC
Maximum Input Current:0.95 A

Output

Number of Outputs:1
Output Connector Diameters:DIN-4 Male
Output Connector Type:DIN-4 Male
Output Voltage (Channel 1):20 VDC
Output Voltage:20 VDC
Additional Output Voltages (VDC):N/A
Output Current (Channel 1):4.50 A
Output Current:4.50 A

Features

Minimum Isolation Voltage:3750V
Polarity:N/A
Product Note:Level VI
AC Power Cord:Included
IP Rating:IP67
Efficiency:89%
Power Rating:90 W
,
