240 Watt Single Output Enclosed Power Supply with PFC Function

4 Volts @ 60 Amps

Features

  • Universal AC input / Full range
  • Built-in active PFC function, PF>0.95
  • High efficiency up to 84.5%
  • Protections: Short circuit / Overload / Over voltage / Over temperature
  • Forced air cooling by built-in DC Fan with fan speed control function
  • 3 years warranty
  • 1U low profile 30mm
  • LED indicator for power on
  • Agency Approvals: UL, cULus, TUV, CB, CE

      • Overview

Product Identification

Type:Auto Switching SMPS
Manufacturer Series:RSP-320

Compliance

Agency Approvals: CB, CCC, CE, CUL, EAC, EN, TUV, UL, IEC/EN 61558-1

Dimensions & Appearance

Style:Enclosed
Color:Silver
Height:1.2 in.
Width:4.5 in.
Length:8.5 in.

Operating conditions

Minimum Operating Temperature:-30°C
Maximum Operating Temperature:70°C

Input

Input Frequency:47 Hz to 63 Hz
Input Voltage:88 VAC to 264 VAC
Maximum Input Current:2.7 A

Output

Number of Outputs:1
Output Voltage (Channel 1):4 VDC
Output Voltage:4 VDC
Output Connector Type:Screw Terminal Block
Output Current (Channel 1):60 A
Output Current:60 A

Features

PFC Function:Yes
Minimum Isolation Voltage:3000V
Efficiency:84.5%
Power Rating:240 W
,
