750 Watt Single Output Enclosed Power Supply with PFC24 Volts @ 31.3 AmpsFeatures
- Universal AC input / Full range
- AC input active surge current limiting
- High efficiency up to 90.5%
- Built-in 12V/0.1A auxiliary power
- Built-in active PFC function, PF>0.97
- Protections: Short circuit / Overload / Over voltage / Over temperature / Fan alarm
- Output voltage can be trimmed between 40 ~ 110% by 2 ~ 5.5VDC external control signal
- Output current can be trimmed between 40 ~ 110% by 2 ~ 5.5VDC external control signal
- Forced air cooling by built-in DC with fan speed control function
- High power density 9.44w/inch³
- 1U low profile 41mm
- DC OK Signal
- Built-in remote ON-OFF control
- Built-in remote sense function
- 5 year warranty
- Agency Approvals: UL, cULus, TUV, CB, CE
Overview
Product Identification
Type:Auto Switching SMPS
Manufacturer Series:RSP-750
Compliance
Agency Approvals: CB, CCC, CE, CUL, EAC, EN, TUV, UL
Dimensions & Appearance
Style:Enclosed
Color:Silver
Height:1.6 in.
Width:5 in.
Length:9.8 in.
Operating conditions
Minimum Operating Temperature:-30°C
Maximum Operating Temperature:70°C
Input
Input Frequency:47 Hz to 63 Hz
Input Voltage:90 VAC to 264 VAC
Maximum Input Current:8.2 A
Output
Number of Outputs:1
Output Voltage (Channel 1):24 VDC
Output Connector Type:Screw Terminal Block
Output Voltage:24 VDC
Output Current (Channel 1):31.3 A
Output Current:31.30 A
Features
PFC Function:Yes
Minimum Isolation Voltage:3000V
Efficiency:90.5%
Power Rating:751.2 W
