AC to DC Switching Enclosed Power Supply Single Output with PFC Function 3.3 Volts 20 Amps 66 Watts

3.3 Volts @ 20 Amps

Specifications

  • Output Power (W): 66
  • Size (L x W x H) inches: 7.1 X 3.9 X 1.2
  • Ripple & Noise (mV p-p): 100
  • Line Regulation (±): 0.5%
  • Load Regulation (±): 1%
  • Efficiency: 83%
  • Frequency Range: 47-63 Hz
  • Voltage Range 85-264 VAC
  • Agency Approvals: UL/CUL/TUV/CCC/CB/CE
  • Universal AC input / Full range
  • Built in active PFC function
  • Protections: short circuit, over voltage, over temperature, overload
  • Cooling by free air convection
  • Built in constant current limiting circuit
  • LED indicator for power on
  • 100% full load burn in test
  • 3 year warranty

Overview

Product Identification

Type:Auto Switching SMPS
Manufacturer Series:RSP-100

Compliance

Agency Approvals: CB, CCC, CE, CUL, EAC, EN, TUV, UL

Dimensions & Appearance

Style:Enclosed
Color:Silver
Height:1.18 in.
Width:3.9 in.
Length:7.05 in.

Operating conditions

Minimum Operating Temperature:-30°C
Maximum Operating Temperature:70°C

Input

Input Frequency:47 Hz to 63 Hz
Input Voltage:85 VAC to 264 VAC
Maximum Input Current:1.1 A

Output

Number of Outputs:1
Output Voltage (Channel 1):3.3 VDC
Output Voltage:3.3 VDC
Output Connector Type:Screw Terminal Block
Output Current (Channel 1):20 A
Output Current:20 A

Features

PFC Function:Yes
Minimum Isolation Voltage:3750V
Efficiency:83%
Power Rating:66 W
,
