AC to DC Switching Encapsulated Power Supply PCB Mount 12 Volts 0.25 Amps 3 Watt

12 Volts @ 0.25 Amps

Specifications

  • Output Power (W): 3
  • Size (L x W x H) inches: 1.5 X 1 X 0.6
  • Ripple & Noise (mV p-p): 150
  • Load Regulation (±): 0.5%
  • Line Regulation (±): 0.5%
  • Efficiency: 78%
  • Agency Approvals: UL/CUL/TUV/CE/CB/LPS
  • Frequency Range: 47 ~ 63 Hz
  • Voltage Range: 85 ~ 305 VAC
  • Universal AC input / Full range
  • Compact size
  • Protections: short circuit, over voltage, overload
  • Complies with EN55022 Class B without additional components
  • Cooling by free air convection
  • Isolation Class 3
  • No load power consumption < 0.75 watts
  • PCB Mount
  • 3 year warranty

Product Identification

Product Type:Power Module SMPS
Manufacturer Series:IRM-03

Compliance

Agency Approvals: CB, CE, CUL, EAC, EN, TUV, UL

Dimensions & Appearance

Style:Encapsulated
Color:Black
Height:0.59 in.
Width:0.95 in.
Length:1.46 in.

Operating conditions

Minimum Operating Temperature:-30°C
Maximum Operating Temperature:85°C

Input

Input Frequency:47 Hz to 63 Hz
Maximum Input Current:0.07 A
Input Voltage:85 VAC to 305 VAC

Output

Number of Outputs:1
Output Voltage:12 VDC
Output Current:0.25 A
Output Connector Type:PC Pins

Features

Minimum Isolation Voltage:3000V
Efficiency:78%
Power Rating:2 W
,
