AC to DC Switching DIN Rail Power Supply 12 Volts 6.3 Amps 75.6 Watts

12 Volts @ 6.3 Amps

Specifications

  • Output Power (W): 75.6
  • Size (L x W x H) inches: 1.26 X 4.93 X 4.02
  • Ripple & Noise (mV p-p): 80
  • Load Regulation (±): 1%
  • Line Regulation (±): 0.5%
  • Efficiency: 85.5%
  • Agency Approvals: UL/CUL/TUV/CE/CB
  • Universal AC input / Full range
  • Can be installed on DIN rail TS-35/7.5 or 15
  • Protections: short circuit, over voltage, over temperature, overload
  • Cooling by free air convection
  • UL 508 (industrial control equipment) approved
  • EN61000-6-2(EN50082-2) industrial immunity level
  • 100% full load burn-in test
  • 2 year warranty

Product Identification

Product Type:DIN Rail Power Supply SMPS
Manufacturer Series:EDR-75

Compliance

Agency Approvals: CB, CE, CUL, EAC, EN, TUV, UL

Dimensions & Appearance

Depth:1.26 in.
Color:Silver
Height:4.02 in.
Width:4.93 in.

Operating conditions

Minimum Operating Temperature:-20°C
Maximum Operating Temperature:60°C

Input

Input Frequency:47 Hz to 63 Hz
Input Voltage:90 VAC to 264 VAC
Maximum Input Current:1.45 A

Output

Number of Outputs:1
Output Voltage:12 VDC
Output Connector Type:Screw Terminal Block
Additional Output Voltages (VDC):N/A
Output Current:6.30 A

Features

PFC Function:No
Low Power Source (LPS):No
Efficiency:85.5%
Power Rating:75.6 W
,
