65.5W AC/DC Enclosed Switching Power Supply Triple Output

+5 Volts @ 5 Amps (Channel 1)
+15 Volts @ 2.2 Amps (Channel 2)
-15 Volts @ 0.5 Amps (Channel 3)

Specifications

  • Size (L x W x H) (inches): 5.1 x 3.9 x 1.5
  • Ripple and Noise (mV p-p): 80 (CH1, CH3); 120 (CH2)
  • Load Regulation: 1.0%
  • Line Regulation: 0.5%
  • Input: 88-264VAC @ 47-63Hz
  • 5G Vibration
  • Able to withstand 300VAC surge input for 5 seconds
  • Short-circuit/overload/overvoltage protection
  • 3-year warranty
  • Certifications: UL/CUL/TUV/CE/CB

Product Identification

Type:Auto Switching SMPS
Product Type:AC to DC Power Supply
Manufacturer Series:RT-65

Compliance

Agency Approvals: CB, CE, CUL, EAC, EN, TUV, UL

Dimensions & Appearance

Style:Multiple Output
Color:Silver
Height:1.5 in.
Width:3.9 in.
Length:5.1 in.

Operating conditions

Minimum Operating Temperature:-25°C
Maximum Operating Temperature:70°C

Input

Input Frequency:47 Hz to 63 Hz
Input Voltage:88 VAC to 264 VAC
Maximum Input Current:2 A

Output

Number of Outputs:3
Output Current (Channel 3):0.5 A
Output Voltage (Channel 3):-15 VDC
Output Voltage (Channel 1):5 VDC
Output Voltage (Channel 2):15 VDC
Output Current (Channel 2):2.20 A
Output Voltage:5 VDC
Additional Output Voltages (VDC): -15, 15
Output Connector Type:Screw Terminal Block
Output Current (Channel 1):5 A
Output Current:5 A

Features

Minimum Isolation Voltage:3000V
Efficiency:78%
Power Rating:65.5 W
,
