624 W Single Output with PFC Function
48 Volts @ 13 Amps
Features:
- Universal AC input / Full range
- Built-in active PFC function, PF>0.95
- Protections: Short circuit / Overload / Over voltage / Over temperature
- With DC OK signal output
- Built-in remote ON-OFF control
- Standby [email protected]
- No load power consumption<0.75W
- Current sharing up to 2400W (3+1) (24V,36V,48V)
- 5 years warranty
- High efficiency up to 89%
- Withstand 300VAC surge input for 5 seconds
- Built-in cooling fan ON-OFF control (by load)
- Built-in remote sense function
Product Identification
Type:Auto Switching SMPS
Manufacturer Series:HRPG-600
Compliance
Agency Approvals: CB, CE, CUL, EAC, EN, TUV, UL
Dimensions & Appearance
Style:Enclosed
Color:Silver
Height:2.5 in.
Width:4.1 in.
Length:8.6 in.
Operating conditions
Minimum Operating Temperature:-30°C
Maximum Operating Temperature:70°C
Input
Input Frequency:47 Hz to 63 Hz
Input Voltage:85 VAC to 264 VAC
Maximum Input Current:8.5 A
Output
Number of Outputs:1
Output Voltage (Channel 1):48 VDC
Output Connector Type:Screw Terminal Block
Output Voltage:48 VDC
Output Current (Channel 1):13 A
Output Current:13 A
Features
PFC Function:Yes
Minimum Isolation Voltage:3000V
Efficiency:89%
Power Rating:624 W
