630W AC/DC ENCLOSED SWITCHING POWER SUPPLY
36Volts @ 17.5Amps
Specifications:
- Size (L x W x H) (inches): 8.6 x 4.1 x 2.5
- Ripple and Noise (mV p-p): 200
- Load Regulation: 0.5%
- Line Regulation: 0.2%
- Input: 85-264VAC @ 47-63Hz
- Built-in active Power Factor Correction function
- Universal AC input
- 3-year warranty
- Certifications: UL/CUL/TUV/CE/CB/PFC
Product Identification
Type:Auto Switching SMPS
Manufacturer Series:HRPG-600
Compliance
Agency Approvals: CB, CE, CUL, EAC, EN, TUV, UL
Dimensions & Appearance
Style:Enclosed
Color:Silver
Height:2.5 in.
Width:4.1 in.
Length:8.6 in.
Operating conditions
Minimum Operating Temperature:-30°C
Maximum Operating Temperature:70°C
Input
Input Frequency:47 Hz to 63 Hz
Input Voltage:88 VAC to 264 VAC
Maximum Input Current:8.5 A
Output
Number of Outputs:1
Output Voltage (Channel 1):36 VDC
Output Connector Type:Screw Terminal Block
Output Voltage:36 VDC
Output Current (Channel 1):17.5 A
Output Current:17.50 A
Features
PFC Function:Yes
Minimum Isolation Voltage:3000V
Efficiency:89%
Power Rating:630 W
