1512W AC/DC ENCLOSED SWITCHING POWER SUPPLY

24 Volts @ 63 Amps

Features

  • Size (L x W x H) (inches): 10.9 x 5.0 x 3.3
  • Ripple and Noise (mV p-p): 150
  • Load Regulation: 0.5%
  • Line Regulation: 0.5%
  • Input: 90-264VAC @ 47-63Hz
  • Built-in active Power Factor Correction function
  • Built-in ON-OFF control and remote sense function
  • Parallel function
  • Universal AC input
  • 3-year warranty
  • Certifications: UL/CUL/TUV/CE/CB/PFC

Overview

Product Identification

Type:Auto Switching SMPS
Manufacturer Series:RSP-1500

Compliance

Agency Approvals: CB, CE, CUL, EAC, EN, TUV, UL

Dimensions & Appearance

Style:Enclosed
Color:Silver
Length:10.9 in.
Height:3.3 in.
Width:5 in.

Operating conditions

Minimum Operating Temperature:-20°C
Maximum Operating Temperature:70°C

Input

Input Frequency:47 Hz to 63 Hz
Input Voltage:90 VAC to 264 VAC
Maximum Input Current:17 A

Output

Number of Outputs:1
Output Voltage (Channel 1):24 VDC
Output Connector Type:Lug Terminal Female
Output Voltage:24 VDC
Output Current (Channel 1):63 A
Output Current:63 A

Features

PFC Function:Yes
Minimum Isolation Voltage:3000V
Efficiency:90%
Power Rating:1512 W
,
