324W AC/DC ENCLOSED SWITCHING POWER SUPPLY
12Volts @ 27Amps
Specifications:
- Size (L x W x H) (inches): 7.8 x 4.1 x 1.6
- Ripple and Noise (mV p-p): 120
- Load Regulation: 0.5%
- Line Regulation: 0.3%
- Input: 85-264VAC @ 47-63Hz
- Built-in active Power Factor Correction function
- Able to withstand 300VAC surge input for 5 seconds
- Universal AC input
- Built-in remote sense function and remote on/off control
- 5-year warranty
- Certifications: UL/CUL/TUV/CE/CB/PFC
Product Identification
Type:Auto Switching SMPS
Manufacturer Series:HRPG-300
Compliance
Agency Approvals: CB, CE, CUL, EAC, EN, TUV, UL
Dimensions & Appearance
Style:Enclosed
Color:Silver
Height:1.6 in.
Width:4.1 in.
Length:7.8 in.
Operating conditions
Minimum Operating Temperature:-30°C
Maximum Operating Temperature:70°C
Input
Input Frequency:47 Hz to 63 Hz
Input Voltage:85 VAC to 264 VAC
Maximum Input Current:5 A
Output
Number of Outputs:1
Output Voltage (Channel 1):12 VDC
Output Voltage:12 VDC
Output Connector Type:Screw Terminal Block
Output Current (Channel 1):27 A
Output Current:27 A
Features
PFC Function:Yes
Minimum Isolation Voltage:3000V
Efficiency:88%
Power Rating:324 W
