152W Single Output with Battery Charger (UPS Function)
Channel 1: 13.8 Volts @ 10.5 Amps (Power Supply)Channel 2: 13.3 Volts @ 0.5 Amps (UPS Charger)
Find out more about MEAN WELL Security Power Solutions.
Features:
- Universal AC input / Full range: 88-264VAC @ 47-63Hz, or 124-370VDC
- Protections: Short circuit / Overload / Over voltage
- Low battery and battery polarity protection
- Cooling by free air convection
- 100% full load burn-in test
- Fixed switching frequency @ PFC 67kHz, PWM 134kHz
- Size: 7.8"L x 4.3"W x 2.0"H
- Weight: 1.9 lbs.
Product Identification
Type:Switching SMPS
Product Type:AC to DC Power Supply
Manufacturer Series:AD-155
Compliance
Agency Approvals: CB, CE, CUL, EAC, EN, TUV, UL
Dimensions & Appearance
Style:Multiple Output
Color:Silver
Height:2 in.
Width:4.3 in.
Length:7.8 in.
Operating conditions
Minimum Operating Temperature:-10°C
Maximum Operating Temperature:60°C
Input
Input Frequency:47 Hz to 63 Hz
Input Voltage:88 VAC to 264 VAC
Maximum Input Current:2.5 A
Output
Number of Outputs:2
Output Current (Channel 2):0.5 A
Output Voltage (Channel 2):13.3 VDC
Output Voltage (Channel 1):13.8 VDC
Additional Output Voltages (VDC):13.3
Output Voltage:13.8 VDC
Output Connector Type:Screw Terminal Block
Output Current (Channel 1):10.5 A
Output Current:11.50 A
Features
Minimum Isolation Voltage:3000V
Efficiency:80%
Power Rating:151.55 W
