AC to DC Switching Enclosed Medical Power Supply Single Output with PFC Function 7.5 Volts 60 Amps 75 Watts

7.5 Volts @ 60 Amps

Specifications

  • Output Power (W): 75
  • Size (L x W x H) inches: 8.59 X 4.131.61
  • Ripple & Noise (mV p-p): 100
  • Line Regulation (±): 0.5%
  • Load Regulation (±): 1%
  • Efficiency: 86.5%
  • Agency Approvals: UL/CUL/CB/CE
  • Universal AC input / Full range
  • Built in active PFC function, PF > 0.95
  • Protections: short circuit, over voltage, over temperature, over current
  • High efficiency up to 89.5%
  • Withstand 300 VAC surge input for 5 seconds
  • Built in constant current limiting circuit
  • Medical safety approved (MOOP Level)
  • Built in cooling fan with ON-OFF control
  • Built in DC OK signal
  • Built in remote ON-OFF control
  • Stand by 5 volt @ 0.3 Amps
  • Built in remote sense function
  • No load power consumption <0.3 watt
  • 5 year warranty

Product Identification

Product Type:Medical Switching SMPS
Manufacturer Series:MSP-450

Compliance

Agency Approvals: CB, CE, CUL, EAC, EN, UL

Dimensions & Appearance

Style:Medical Enclosed
Color:Silver
Height:1.6 in.
Width:4.1 in.
Length:8.6 in.

Operating conditions

Minimum Operating Temperature:-40°C
Maximum Operating Temperature:70°C

Input

Input Frequency:47 Hz to 63 Hz
Input Voltage:85 VAC to 264 VAC
Maximum Input Current:5 A

Output

Number of Outputs:1
Output Voltage:7.5 VDC
Output Connector Type:Screw Terminal Block
Output Current:60 A

Features

PFC Function:Yes
Efficiency:86.5%
Power Rating:450 W
,
