125W Dual Output Switching Power Supply


CH1: 48 Volts @ 2 Amps
CH2: 24 Volts @ 2 Amps

Features:
  • Protections: Short circuit / Overload / Over voltage
  • Cooling by free air convection
  • LED indicator for power on
  • 100% full load burn-in test
  • All using 105°C long life electrolytic capacitors
  • Withstand 300VAC surge input for 5 seconds
  • High operating temperature up to 70°C
  • Withstand 5G vibration test
  • High efficiency, long life, and high reliability
  • 3 years warranty

Product Identification

Type:Switch Selectable SMPS
Product Type:AC to DC Power Supply
Manufacturer Series:RD-125

Compliance

Agency Approvals: CB, CE, CUL, EAC, EN, TUV, UL

Dimensions & Appearance

Style:Multiple Output
Color:Silver
Height:1.5 in.
Width:3.9 in.
Length:7.8 in.

Operating conditions

Minimum Operating Temperature:-25°C
Maximum Operating Temperature:70°C

Input

Input Frequency:47 Hz to 63 Hz
Input Voltage:88 VAC to 132 VAC, 176 VAC to 264 VAC
Maximum Input Current:3 A

Output

Number of Outputs:2
Output Current (Channel 2):2 A
Output Voltage (Channel 2):24 VDC
Output Voltage (Channel 1):48 VDC
Output Current (Channel 1):2 A
Output Connector Type:Screw Terminal Block
Additional Output Voltages (VDC):24
Output Voltage:48 VDC
Output Current:2.50 A

Features

Minimum Isolation Voltage:3000V
Efficiency:86%
Power Rating:144 W
,
