125W Dual Output Switching Power Supply
CH1: 24 Volts @ 2 AmpsCH2: 48 Volts @ 2 Amps
Features:
- Isolated output & GND for CH1,CH2
- AC input range selectable by switch
- Withstand 300VAC surge input for 5 seconds
- Protections: Short circuit / Overload / Over voltage
- All using 105°C long life electrolytic capacitors
- Withstand 5G vibration test
- LED indicator for power on
- 100% full load burn-in test
- High reliability
- 3 years warranty
Product Identification
Type:Auto Switching SMPS
Product Type:AC to DC Power Supply
Manufacturer Series:RID-125
Compliance
Agency Approvals: CB, CE, CUL, EAC, EN, TUV, UL
Dimensions & Appearance
Style:Multiple Output
Color:Silver
Height:1.5 in.
Width:3.9 in.
Length:7.8 in.
Operating conditions
Minimum Operating Temperature:-20°C
Maximum Operating Temperature:70°C
Input
Input Frequency:47 Hz to 63 Hz
Input Voltage:88 VAC to 132 VAC, 176 VAC to 264 VAC
Maximum Input Current:3 A
Output
Number of Outputs:2
Output Current (Channel 2):2 A
Output Voltage (Channel 2):48 VDC
Output Voltage (Channel 1):24 VDC
Output Current (Channel 1):2 A
Output Connector Type:Screw Terminal Block
Output Voltage:24 VDC
Additional Output Voltages (VDC):48
Output Current:4 A
Features
Minimum Isolation Voltage:3000V
Efficiency:86%
Power Rating:144 W
