60W Single Output Switching LED Power Supply
36 Volts @ 1.67 AmpsFeatures:
- Constant voltage design
- Universal AC input / Full range
- Fully encapsulated with IP67 level
- Withstand 300VAC surge input for 5 seconds
- Protections: Short circuit / Overload / Over voltage
- Fully isolated plastic case
- Cooling by free air convection
- UL1310 Class 2 power unit, pass LPS
- 100% full load burn-in test
- Low cost, high reliability
- Suitable for LED lighting and moving sign applications
- 2 years warranty
Overview
Product Identification
Product Type:Auto Switching SMPS
Manufacturer Series:LPV-60
Compliance
Agency Approvals: CB, CE, CUL, EAC, EN, UKCA, UL
Dimensions & Appearance
Style:Enclosed
Color:White
Height:1.25 in.
Width:1.67 in.
Length:6.39 in.
Operating conditions
Minimum Operating Temperature:-30°C
Maximum Operating Temperature:70°C
Input
Input Frequency:47 Hz to 63 Hz
Input Voltage:90 VAC to 264 VAC
Maximum Input Current:1.2 A
Output
Number of Outputs:1
Output Connector Type:Stripped and Tinned
Output Voltage:36 VDC
Output Current:1.67 A
Output Range:N/A
Features
PFC Function:No
Minimum Isolation Voltage:3000V
IP Rating:IP67
Efficiency:86%
Power Rating:60 W
