20W Single Output LED Power Supply


36 Volts @ 0.84 Amps

Features:
  • Universal AC input / Full range(up to 295VAC)
  • Fully isolated plastic case with IP64 level
  • Built-in constant current limiting circuit with adjustable OCP level
  • Protections: Short circuit/Over load/Over voltage/Over temperature
  • Built-in active PFC function
  • Pass LPS
  • IP64 design for indoor or outdoor installations
  • Cooling by free air convection
  • 100% full load burn-in test
  • High reliability
  • Suitable for LED lighting and moving sign applications
  • Compliance to worldwide safety regulations for lighting
  • 2 years warranty

Product Identification

Product Type:Auto Switching SMPS
Manufacturer Series:PLN-30

Compliance

Agency Approvals: CB, CCC, CE, CSA, CUL, EAC, EN, TUV, UL, UL, CUL, CSA, TUV, CB, CE, EN, EAC, CCC

Dimensions & Appearance

Style:Enclosed
Color:White
Height:1.18 in.
Width:1.85 in.
Length:5.70 in.

Operating conditions

Minimum Operating Temperature:-30°C
Maximum Operating Temperature:50°C

Input

Input Frequency:47 Hz to 63 Hz
Input Voltage:90 VAC to 295 VAC
Maximum Input Current:0.4 A

Output

Number of Outputs:1
Output Connector Type:Stripped and Tinned
Output Voltage:36 VDC
Output Current:0.84 A
Output Range:N/A

Features

PFC Function:Yes
Minimum Isolation Voltage:3750V
IP Rating:IP64
Efficiency:85%
Power Rating:30.24 W
,
