18W Single Output Switching LED Power Supply
36 Volts @ 0.5 Amps
Features:
- 180-264VAC input only
- Fully encapsulated with IP67 level
- Protections: Short circuit / Overload / Over voltage / Over temperature
- Cooling by free air convection
- Pass LPS
- 100% full load burn-in test
- Suitable for LED lighting and moving sign applications
- High reliability / Low cost
- 2 years warranty
Product Identification
Product Type:Auto Switching SMPS
Manufacturer Series:LPH-18
Compliance
Agency Approvals: CB, CE, EAC, EN, TUV
Dimensions & Appearance
Style:Enclosed
Color:Beige
Height:0.86 in.
Width:1.18 in.
Length:5.51 in.
Operating conditions
Minimum Operating Temperature:-30°C
Maximum Operating Temperature:70°C
Input
Input Frequency:47 Hz to 63 Hz
Maximum Input Current:0.3 A
Input Voltage:180 VAC to 264 VAC
Output
Number of Outputs:1
Output Connector Type:Stripped and Tinned
Output Current:0.50 A
Output Voltage:36 VDC
Output Range:N/A
Features
PFC Function:No
Minimum Isolation Voltage:3000V
IP Rating:IP67
Efficiency:83%
Power Rating:18 W
