60W Enclosed LED Power Supply with PFC Function

15 Volts @ 4 Amps

Features:

  • Suitable for LED lighting and moving sign applications
  • Input: 90-295VAC @ 47-63Hz, or 127-417VDC
  • Size: 7.1"L x 2.4"W x 1.4"H
  • Ripple and Noise: 2400mVp-p
  • Load Regulation: ±10.0%
  • Line Regulation: ±4.0%
  • Universal AC input/full range
  • 100% full-load burn-in test
  • Constant voltage and current
  • Short-circuit, Overload, Over-voltage protection
  • 2-year warranty
  • Certification: UL/CUL/TUV/CE

    • Product Identification

    Product Type:Auto Switching SMPS
    Manufacturer Series:PLN-60

    Compliance

    Agency Approvals: CB, CCC, CE, EAC, EN, TUV, CUL, CUL, TUV, CB, CE, EN, EAC, CCC

    Dimensions & Appearance

    Style:Enclosed
    Color:White
    Height:1.37 in.
    Width:2.42 in.
    Length:7.12 in.

    Operating conditions

    Minimum Operating Temperature:-30°C
    Maximum Operating Temperature:50°C

    Input

    Input Frequency:47 Hz to 63 Hz
    Input Voltage:90 VAC to 295 VAC
    Maximum Input Current:0.8 A

    Output

    Number of Outputs:1
    Output Range:14.5 VDC to 16.2 VDC
    Output Voltage:15 VDC
    Output Connector Type:Stripped and Tinned
    Output Current:4 A

    Features

    PFC Function:Yes
    Minimum Isolation Voltage:3750V
    IP Rating:IP64
    Efficiency:86%
    Power Rating:60 W
    ,
