16W Single Output Switching LED Power Supply

12 - 48 Volts @ 350 milliamps (mA)

Features:
  • Constant current mode power supply
  • Universal AC input / Full range
  • Protections: Short circuit / Overload / Over voltage
  • Fully isolated plastic case
  • Small and compact size
  • Cooling by free air convection
  • Pass LPS
  • 100% full load burn-in test
  • Suitable for LED lighting and moving sign applications
  • Low cost / High reliability
  • 2 years warranty

Product Identification

Product Type:Auto Switching SMPS
Manufacturer Series:APC-16

Compliance

Agency Approvals: CE, CUL, EAC, EN, UL, UL, CUL, CE, EN, EAC

Dimensions & Appearance

Style:Enclosed
Color:White
Height:1.52 in.
Width:2.67 in.
Length:8.66 in.

Operating conditions

Minimum Operating Temperature:-30°C
Maximum Operating Temperature:70°C

Input

Input Frequency:47 Hz to 63 Hz
Input Voltage:90 VAC to 264 VAC
Maximum Input Current:0.5 A

Output

Number of Outputs:1
Output Current (Channel 1):0.35 A
Output Voltage (Channel 1):12 VDC to 48 VDC
Output Range:12 VDC to 48 VDC
Output Connector Type:Stripped and Tinned
Output Current:0.35 A
Output Voltage:See Output Range

Features

PFC Function:No
IP Rating:IP42
Minimum Isolation Voltage:3750V
Efficiency:84%
Power Rating:16.8 W
,
