240W DIN-RAIL SWITCHING POWER SUPPLY
48 Volts @ 5 AmpSpecifications
- Universal AC input range
- Protections: Short-circuit, Overload, Overvoltage, Overtemperature
- 100% Full load burn-in test
- Soft-start circuit, limiting AC surge current
- Input Voltage: 88-264VAC @ 47-63Hz, or 120-370VD
- Input Current @ Full load: 2.6A(115V) / 1.3A(350V)
- Size: 2.5" x 4.9" x 4.5"
- Weight: 2.4 lbs.
- 3-year warranty
Overview
Product Identification
Product Type:DIN Rail Power Supply SMPS
Manufacturer Series:SDR-240
Compliance
Agency Approvals: CB, CE, CUL, EAC, EN, SEMI, TUV, UL
Dimensions & Appearance
Color:Silver
Depth:2.48 in.
Height:4.47 in.
Width:4.93 in.
Operating conditions
Minimum Operating Temperature:-25°C
Maximum Operating Temperature:70°C
Input
Input Frequency:47 Hz to 63 Hz
Input Voltage:88 VAC to 264 VAC
Maximum Input Current:2.6 A
Output
Number of Outputs:1
Output Connector Type:Screw Terminal Block
Output Voltage:48 VDC
Additional Output Voltages (VDC):N/A
Output Current:5 A
Features
Low Power Source (LPS):No
PFC Function:Yes
Efficiency:94%
Power Rating:240 W
