20W DIN-RAIL SWITCHING POWER SUPPLY
12 Volts @ 1.67 AmpsFeatures - Universal AC input range
- Protections: Short-circuit, Overload, Overvoltage
- 100% Full load burn-in test
- Soft-start circuit, limiting AC surge current
- Input Voltage: 85-264VAC @ 47-63Hz, or 120-370VDC
- Input Current @ Full load: 0.55A(115V) / 0.35A(230V)
- Size: 3.9" x 0.9" x 3.5"
- Weight: 0.4 lbs.
- 3-year warranty
- Universal AC input range
- Protections: Short-circuit, Overload, Overvoltage
- 100% Full load burn-in test
- Soft-start circuit, limiting AC surge current
- Input Voltage: 85-264VAC @ 47-63Hz, or 120-370VDC
- Input Current @ Full load: 0.55A(115V) / 0.35A(230V)
- Size: 3.9" x 0.9" x 3.5"
- Weight: 0.4 lbs.
- 3-year warranty
Overview
Product Identification
Product Type:DIN Rail Power Supply SMPS
Manufacturer Series:MDR-20
Compliance
Agency Approvals: CB, CE, CUL, EAC, EN, TUV, UL
Dimensions & Appearance
Depth:0.89 in.
Color:White
Width:3.54 in.
Height:3.94 in.
Operating conditions
Minimum Operating Temperature:-20°C
Maximum Operating Temperature:70°C
Input
Input Frequency:47 Hz to 63 Hz
Input Voltage:85 VAC to 264 VAC
Maximum Input Current:0.55 A
Output
Number of Outputs:1
Output Voltage:12 VDC
Output Connector Type:Screw Terminal Block
Additional Output Voltages (VDC):N/A
Output Current:1.67 A
Features
PFC Function:No
Low Power Source (LPS):No
Efficiency:80%
Power Rating:20 W
