96W DIN-Rail Switching Power Supply

48 Volts @ 2 Amps

Features

  • Universal AC input range
  • Protections: Short-circuit, Overload, Overvoltage, Overtemperature
  • 100% Full load burn-in test
  • Soft-start circuit, limiting AC surge current
  • Input Voltage: 85-264VAC @ 47-63Hz, or 120-370VDC
  • Input Current @ Full load: 1.3A(115V) / 0.8A(230V)
  • Size: 3.9" x 2.2" x 3.5"
  • Weight: 0.9 lbs.
  • 3-year warranty

      • Overview

Product Identification

Manufacturer Series:MDR-100
Product Type:DIN Rail Power Supply SMPS

Compliance

Agency Approvals: CE, CUL, EAC, EN, TUV, UL

Dimensions & Appearance

Depth:2.17 in.
Color:White
Width:3.54 in.
Height:3.94 in.

Operating conditions

Minimum Operating Temperature:-10°C
Maximum Operating Temperature:60°C

Input

Input Frequency:47 Hz to 63 Hz
Input Voltage:85 VAC to 264 VAC
Maximum Input Current:1.3 A

Output

Number of Outputs:1
Output Connector Type:Screw Terminal Block
Output Voltage:48 VDC
Additional Output Voltages (VDC):N/A
Output Current:2 A

Features

Low Power Source (LPS):No
PFC Function:Yes
Efficiency:88%
Power Rating:96 W
,
