92.5 mm x 92.5 mm x 38 mm Tube Axial Fan 24 VDC Ball Bearing 125CFM 62dBA 12" Wires
Features
- Voltage Rating: 24 VDC
- Height: 92.5 mm
- Width: 92.5 mm
- Depth: 38 mm
- Air Flow (CFM): 125
- Bearing: Ball
- Current Rating: 950 mA
- Power Rating: 22.8 W
- Agency Approvals: UL, CUL, TUV
- Noise (dBA): 62
- Termination: 12" Wires
- Product Type: 92mm x 92mm DC Fan
- Speed: 5400 rpm
- Maximum Pressure: 0.74 in.
- Motor Drive Type: Brushless DC, Auto Restart, Polarity Protected
Overview
Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 5400 rpm.
Product Identification
Product Type:DC Fan
Compliance
Dimensions & Appearance
Depth:38 mm
Height:92.5 mm
Width:92.5 mm
Features
Bearing:Ball
Motor Drive Type:Brushless DC, Auto Restart, Polarity Protected
Noise (dBA):62
Maximum Pressure:0.74 in.
Voltage Rating:24 VDC
Speed:5400 rpm
Termination:12" Wires
Air Flow (CFM):125
Power Rating:22.8 W
Current Rating:950 mA
