92 mm x 92 mm x 38 mm Tube Axial Fan 48 VDC Ball Bearing 78CFM 50dBA 12" Wires

Features

  • Voltage Rating: 48 VDC
  • Height: 92 mm
  • Width: 92 mm
  • Depth: 38 mm
  • Air Flow (CFM): 78
  • Bearing: Ball
  • Current Rating: 150 mA
  • Power Rating: 7.2 W
  • Agency Approvals: UL, CUL, TUV, CE
  • Noise (dBA): 50
  • Termination: 12" Wires
  • Product Type: 92mm x 92mm DC Fan
  • Speed: 3500 rpm
  • IP Rating: IP68
  • Maximum Pressure: 0.42 in.
  • Motor Drive Type: Brushless DC, Auto Restart, Polarity Protected, Electronically Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 3500 rpm.

,
