92 mm x 92 mm x 38 mm Tube Axial Fan 48 VDC Ball Bearing 147.2CFM 67.1dBA 12" Wires

Orion Fans

Jameco Part #:

Manufacturer #:

Primary datasheet

Product Price:

$27.750

In Stock: 0

Quantity	Unit Price	You Save	Discount
2+	$27.750	-	-
10+	$25.950	1.80	6.49%
50+	$24.450	3.30	11.89%

Features

Voltage Rating: 48 VDC
Height: 92 mm
Width: 92 mm
Depth: 38 mm
Air Flow (CFM): 147.2
Bearing: Ball
Current Rating: 600 mA
Power Rating: 28.8 W
Agency Approvals: UL, CUL, TUV, CE, UKCA
Noise (dBA): 67.1
Termination: 12" Wires
Product Type: 92mm x 92mm DC Fan
Speed: 7000 rpm
Maximum Pressure: 1.4 in.
Motor Drive Type: Brushless DC, Auto Cutoff, Auto Restart, Electronically Protected, Polarity Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 7000 rpm.
