92 mm x 92 mm x 38 mm Tube Axial Fan 230 VAC Ball Bearing 27CFM 23.6dBA Terminals

Features

  • Voltage Rating: 230 VAC
  • Height: 92 mm
  • Width: 92 mm
  • Depth: 38 mm
  • Air Flow (CFM): 27
  • Bearing: Ball
  • Current Rating: 30 mA
  • Power Rating: 7 W
  • Agency Approvals: UL, CUL, TUV, CE, UKCA
  • Noise (dBA): 23.6
  • Termination: Terminals
  • Product Type: 92mm x 92mm AC Fan
  • Speed: 1850 rpm
  • IP Rating: IP55
  • Maximum Pressure: 0.11 in.
  • Motor Drive Type: Shaded Pole, Impedance Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 1850 rpm.

,
