92 mm x 92 mm x 38 mm Tube Axial Fan 115 VAC Ball Bearing 55CFM 40.1dBA 12" Wires

Orion Fans

Jameco Part #:

Manufacturer #:

Primary datasheet

Product Price:

$33.450

In Stock: 0

Quantity	Unit Price	You Save	Discount
2+	$33.450	-	-
10+	$31.350	2.10	6.28%
50+	$29.450	4.00	11.96%

Features

Voltage Rating: 115 VAC
Height: 92 mm
Width: 92 mm
Depth: 38 mm
Air Flow (CFM): 55
Bearing: Ball
Current Rating: 130 mA
Power Rating: 15 W
Agency Approvals: UL, CUL, TUV, CE, UKCA
Noise (dBA): 40.1
Termination: 12" Wires
Product Type: 92mm x 92mm AC Fan
Speed: 3150 rpm
IP Rating: IP55
Maximum Pressure: 0.22 in.
Motor Drive Type: Shaded Pole, Impedance Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 3150 rpm.
