92 mm x 92 mm x 25 mm Tube Axial Fan 48 VDC Ball Bearing 25CFM 23dBA 12" Wires

Features

  • Voltage Rating: 48 VDC
  • Height: 92 mm
  • Width: 92 mm
  • Depth: 25 mm
  • Air Flow (CFM): 25
  • Bearing: Ball
  • Current Rating: 40 mA
  • Power Rating: 1.92 W
  • Agency Approvals: UL, CUL, TUV, CE
  • Noise (dBA): 23
  • Termination: 12" Wires
  • Product Type: 92mm x 92mm DC Fan
  • Speed: 1800 rpm
  • IP Rating: IP68
  • Maximum Pressure: 0.12 in.
  • Motor Drive Type: Brushless DC, Auto Restart, Polarity Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 1800 rpm.

,
