90W 5V 18A DC-DC Converter 12Vin

Output: 5 Volts @ 18 Amps
Input range: 9.5 to 18 VDC

Features

  • 2:1 wide input range
  • Typical input: 12V @ 9.7A
  • Protection against: Short circuit/Overload/Over-Voltage
  • 1500VAC I/O isolation
  • Built-in EMI filter, low ripple noise
  • Value-priced
  • High reliability
  • 2 year warranty

Product Identification

Type:Step Down
Product Type:DC to DC Power Supply SMPS
Manufacturer Series:SD-100

Compliance

Agency Approvals:CE, EN, EAC

Dimensions & Appearance

Mounting:Enclosed
Height:1.5 in.
Width:3.9 in.
Length:7.8 in.

Operating conditions

Minimum Operating Temperature:-15°C
Maximum Operating Temperature:60°C

Packaging

Package:Enclosed

Input

Input Voltage Range:9.5 VDC to 18 VDC
Input Voltage:12 VDC
Maximum Input Current:9.7 A

Output

Number of Outputs:1
Output Voltage:5 VDC
Output Connector Type:Screw Terminal Block
Additional Output Voltages (VDC):N/A
Output Current:18 A

Features

Switching Regulator:Yes
Pins:7
Efficiency:78%
Power Rating:90 W
,
