80x80x25mm Tubeaxial Fan 12 VDC Brushless Dual Ball Bearing 12" Wires 114 CFM
Features
- Voltage Rating: 12 VDC
- Length: 80 mm
- Width: 80 mm
- Height: 25 mm
- Air Flow (CFM): 114.02
- Bearing: Dual Ball
- Current Rating: 3.3 A
- Power Rating: 39.6 W
- Agency Approvals: UL, CUL, CE
- Noise (dBA): 73.7
- Connection (Leads): (4) 12" Wires, PWM + FG
- Speed: 15000 rpm
- Product Type: Fan
Overview
This cooling fan also known as a case fan or muffin fan, is an active cooling device mainly used in household electronics or industrial product equipment. They can continuously provide stable air volume that would help to prevent device overheating.
Product Identification
Product Type:DC Fan
Compliance
Dimensions & Appearance
Depth:25 mm
Height:80 mm
Width:80 mm
Features
Bearing:Dual Ball
Air Flow (CFM):114.02
Noise (dBA):73.7
Voltage Rating:12 VDC
Termination:12" Wires (4), PWM + FG
Speed:15000 rpm
Power Rating:39.60 W
Current Rating:3300 mA
