80W Single Output Switching LED Power Supply

80 Watt, 42V @ 1.95A

Features

  • "B" model - Constant current level adjustable through output cable with 1-10VDC or 10V PWM signal or resistance
  • Universal AC input / Full range (up to 305VAC)
  • Built-in active PFC function
  • Protections: Short circuit / Over current / Over voltage / Over temperature
  • Cooling by free air convection
  • IP67 design for indoor or outdoor installations
  • Class 2 power unit
  • Type HL LED Driver for use in Class I, Division 2 hazardous(Classified) location luminaires
  • Suitable for LED lighting and moving sign applications
  • Compliance to worldwide safety regulations for lighting
  • Suitable for dry / damp / wet locations
  • 7 years warranty

      • Overview

Product Identification

Product Type:Auto Switching SMPS
Manufacturer Series:HLG-80H

Compliance

Agency Approvals: CB, CCC, CE, EAC, EN, TUV, CUL

Dimensions & Appearance

Style:Enclosed
Color:Silver
Height:1.53 in.
Width:2.42 in.
Length:7.7 in.

Operating conditions

Minimum Operating Temperature:-40°C
Maximum Operating Temperature:80°C

Input

Input Frequency:47 Hz to 63 Hz
Input Voltage:90 VAC to 305 VAC
Maximum Input Current:0.85 A

Output

Number of Outputs:1
Output Connector Type:Stripped and Tinned
Output Voltage:42 VDC
Output Current:1.95 A
Output Range:N/A

Features

PFC Function:Yes
Minimum Isolation Voltage:3750V
IP Rating:IP67
Efficiency:91%
Power Rating:81.9 W
,
