80 Position 4 Row Through Hole Connector Header 0.100" (2.54mm)

Features

  • Connector Type: Header
  • Contact Type: Male Pin
  • Pitch - Mating: 0.100" (2.54mm)
  • Number of Positions: 80
  • Number of Rows: 4
  • Number of Positions Loaded: All
  • Style: Board to Cable/Wire
  • Shrouding: Shrouded - 4 Wall
  • Mounting Type: Through Hole
  • Termination: Solder
  • Fastening Type: Push-Pull
  • Contact Length - Post: 0.256" (6.50mm)
  • Insulation Height: 0.848" (21.54mm)
  • Contact Shape: Square
  • Contact Finish - Mating: Gold
  • Insulation Material: Polybutylene Terephthalate (PBT), Glass Filled

Overview

Product Identification

Manufacturer Series:ValuePro

Dimensions & Appearance

Body Orientation:Header

Features

Number of Rows:4
Housing Color:Blue
Number of Contacts:80
Gender:Male Pin
Pitch:2.54 mm
Voltage Rating:N/A
Current Rating:N/A
,
