80 mm x 80 mm x 38 mm Tube Axial Fan 48 VDC Ball Bearing 89CFM 62.5dBA 12" Wires (4)

Features

  • Voltage Rating: 48 VDC
  • Height: 80 mm
  • Width: 80 mm
  • Depth: 38 mm
  • Air Flow (CFM): 89
  • Bearing: Ball
  • Current Rating: 360 mA
  • Power Rating: 72 W
  • Agency Approvals: UL, CUL, TUV, CE, UKCA
  • Noise (dBA): 62.5
  • Termination: 12" Wires (4)
  • Product Type: 80mm x 80mm DC Fan
  • Speed: 6200 rpm
  • Maximum Pressure: 0.75 in.
  • Additional Features: Open Collector Tach Output and PWM
  • Motor Drive Type: Brushless DC, Auto Cutoff, Auto Restart, Electronically Protected, Polarity Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 6200 rpm.

,
