80 mm x 80 mm x 38 mm Tube Axial Fan 48 VDC Ball Bearing 130CFM 66.5dBA 12" Wires

Orion Fans

Jameco Part #:

Manufacturer #:

Primary datasheet

Product Price:

$18.450

In Stock: 0

Quantity	Unit Price	You Save	Discount
3+	$18.450	-	-
12+	$17.250	1.20	6.5%
48+	$16.150	2.30	12.47%

Features

Voltage Rating: 48 VDC
Height: 80 mm
Width: 80 mm
Depth: 38 mm
Air Flow (CFM): 130
Bearing: Ball
Current Rating: 900 mA
Power Rating: 43.2 W
Agency Approvals: UL, CUL, TUV, CE, UKCA
Noise (dBA): 66.5
Termination: 12" Wires
Product Type: 80mm x 80mm DC Fan
Speed: 8925 rpm
Maximum Pressure: 2 in.
Motor Drive Type: Brushless DC, Auto Cutoff, Auto Restart, Polarity Protected, Electronically Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 8925 rpm.
