80 mm x 80 mm x 38 mm Tube Axial Fan 24 VDC Ball Bearing 89CFM 62.5dBA 12" Wires Tach Output and PWM

Jameco Part #:

Manufacturer #:

Primary datasheet

Product Price:

$24.750

In Stock: 0

Quantity	Unit Price	You Save	Discount
3+	$24.750	-	-
12+	$23.250	1.50	6.06%
48+	$21.850	2.90	11.72%

80 mm x 80 mm x 38 mm Tube Axial Fan 24 VDC Ball Bearing 89CFM 62.5dBA 12" Wires (4)

Features

Voltage Rating: 24 VDC
Height: 80 mm
Width: 80 mm
Depth: 38 mm
Air Flow (CFM): 89
Bearing: Ball
Current Rating: 650 mA
Power Rating: 36 W
Agency Approvals: UL, CUL, TUV, CE, UKCA
Noise (dBA): 62.5
Termination: 12" Wires (4)
Product Type: 80mm x 80mm DC Fan
Speed: 6200 rpm
Maximum Pressure: 0.75 in.
Additional Features: Open Collector Tach Output and PWM
Motor Drive Type: Brushless DC, Auto Cutoff, Auto Restart, Electronically Protected, Polarity Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 6200 rpm.
