80 mm x 80 mm x 32 mm Tube Axial Fan 12 VDC Ball Bearing 71CFM 48dBA 12" Wires
Features
- Voltage Rating: 12 VDC
- Height: 80 mm
- Width: 80 mm
- Depth: 32 mm
- Air Flow (CFM): 71
- Bearing: Ball
- Current Rating: 500 mA
- Power Rating: 6 W
- Agency Approvals: UL, CUL, TUV, CE
- Noise (dBA): 48
- Termination: 12" Wires
- Product Type: 80mm x 80mm DC Fan
- Speed: 5500 rpm
- IP Rating: IP68
- Maximum Pressure: 0.61 in.
- Motor Drive Type: Brushless DC, Auto Restart, Polarity Protected, Electronically Protected
Overview
Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 5500 rpm.
Product Identification
Product Type:DC Fan
Compliance
Dimensions & Appearance
Depth:32 mm
Height:80 mm
Width:80 mm
Features
Bearing:Ball
Noise (dBA):48
Motor Drive Type:Brushless DC, Auto Restart, Polarity Protected, Electronically Protected
IP Rating:IP68
Voltage Rating:12 VDC
Maximum Pressure:0.61 in.
Air Flow (CFM):71
Speed:5500 rpm
Termination:12" Wires
Power Rating:6 W
Current Rating:500 mA
