80 mm x 80 mm x 25 mm Tube Axial Fan 24 VDC Sealed Sleeve Bearing 40.1CFM 33dBA 12" Wires

Orion Fans

Jameco Part #:

Manufacturer #:

Primary datasheet

Product Price:

$8.450

In Stock: 0

Quantity	Unit Price	You Save	Discount
6+	$8.450	-	-
30+	$7.850	0.60	7.1%
90+	$7.350	1.10	13.02%

Features

Voltage Rating: 24 VDC
Height: 80 mm
Width: 80 mm
Depth: 25 mm
Air Flow (CFM): 40.1
Bearing: Sealed Sleeve
Current Rating: 120 mA
Power Rating: 2.88 W
Agency Approvals: UL, CUL, TUV
Noise (dBA): 33
Termination: 12" Wires
Product Type: 80mm x 80mm DC Fan
Speed: 3300 rpm
Maximum Pressure: 0.23 in.
Motor Drive Type: Brushless DC, Auto Restart, Polarity Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Sealed Sleeve bearing system of the tube axial fan is designed to operate up to 3300 rpm.
