80 mm x 80 mm x 25 mm Tube Axial Fan 24 VDC Ball Bearing 40.1CFM 33dBA 12" Wires Tach Output | Jameco.com

Orion Fans

80 mm x 80 mm x 25 mm Tube Axial Fan 24 VDC Ball Bearing 40.1CFM 33dBA 12" Wires Tach Output

Jameco Part #:

Manufacturer #:

Primary datasheet

Product Price:

$14.250

In Stock: 0

Quantity	Unit Price	You Save	Discount
4+	$14.250	-	-
20+	$13.250	1.00	7.02%
80+	$12.250	2.00	14.04%

80 mm x 80 mm x 25 mm Tube Axial Fan 24 VDC Ball Bearing 40.1CFM 33dBA 12" Wires (3)

Features

Voltage Rating: 24 VDC
Height: 80 mm
Width: 80 mm
Depth: 25 mm
Air Flow (CFM): 40.1
Bearing: Ball
Current Rating: 120 mA
Power Rating: 2.88 W
Agency Approvals: UL, CUL, TUV, CE
Noise (dBA): 33
Termination: 12" Wires (3)
Product Type: 80mm x 80mm DC Fan
Speed: 3300 rpm
Maximum Pressure: 0.23 in.
Additional Features: Open Collector Tach Output
Motor Drive Type: Brushless DC, Auto Restart, Polarity Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 3300 rpm.
