80 mm x 80 mm x 25 mm Tube Axial Fan 24 VDC Ball Bearing 21.9CFM 21dBA 12" Wires
Features
- Voltage Rating: 24 VDC
- Height: 80 mm
- Width: 80 mm
- Depth: 25 mm
- Air Flow (CFM): 21.9
- Bearing: Ball
- Current Rating: 80 mA
- Power Rating: 1.92 W
- Agency Approvals: UL, CUL, TUV, CE
- Noise (dBA): 21
- Termination: 12" Wires
- Product Type: 80mm x 80mm DC Fan
- Speed: 2000 rpm
- Maximum Pressure: 0.1 in.
- Motor Drive Type: Brushless DC, Auto Restart, Polarity Protected
Overview
Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 2000 rpm.
Product Identification
Product Type:DC Fan
Compliance
Dimensions & Appearance
Depth:25 mm
Height:80 mm
Width:80 mm
Features
Bearing:Ball
Noise (dBA):21
Maximum Pressure:0.1 in.
Speed:2000 rpm
Motor Drive Type:Brushless DC, Auto Restart, Polarity Protected
Voltage Rating:24 VDC
Power Rating:1.92 W
Termination:12" Wires
Air Flow (CFM):21.9
Current Rating:80 mA
