80 mm x 80 mm x 15 mm Tube Axial Fan 24 VDC Ball Bearing 31CFM 34.2dBA 12" Wires (3)

Features

  • Voltage Rating: 24 VDC
  • Height: 80 mm
  • Width: 80 mm
  • Depth: 15 mm
  • Air Flow (CFM): 31
  • Bearing: Ball
  • Current Rating: 100 mA
  • Power Rating: 2.4 W
  • Agency Approvals: UL, CUL, TUV, CE, UKCA
  • Noise (dBA): 34.2
  • Termination: 12" Wires (3)
  • Product Type: 80mm x 80mm DC Fan
  • Speed: 3050 rpm
  • Maximum Pressure: 0.11 in.
  • Additional Features: Open Collector Tach Output
  • Motor Drive Type: Brushless DC, Auto Restart, Polarity Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 3050 rpm.

Product Identification

Additional Feature:Open Collector Tach Output
Product Type:DC Fan

Compliance

RoHS Status:ROHS Compliant
Compliance:Compliance Docs
Agency Approvals: CE, CUL, TUV, UKCA, UL

Dimensions & Appearance

Depth:15 mm
Height:80 mm
Width:80 mm

Features

Bearing:Ball
Maximum Pressure:0.11 in.
Noise (dBA):34.2
Motor Drive Type:Brushless DC, Auto Restart, Polarity Protected
Speed:3050 rpm
Voltage Rating:24 VDC
Air Flow (CFM):31
Power Rating:2.4 W
Termination:12" Wires (3)
Current Rating:100 mA
,
