76.8W AC/DC Enclosed Switching Power Supply



48 Volts @ 1.6 Amps

Specifications

  • Size (L x W x H) (inches): 5.1 x 3.9 x 1.5
  • Ripple and Noise (mV p-p): 120
  • Load Regulation: 1.0%
  • Line Regulation: 0.5%
  • Input: 88-264VAC @ 47-63Hz
  • 5G Vibration
  • Able to withstand 300VAC surge input for 5 seconds
  • Short-circuit/overload/overvoltage protection
  • 3-year warranty
  • Certifications: UL/CUL/TUV/CE/CB

    • Product Identification

    Type:Auto Switching SMPS
    Manufacturer Series:RS-75

    Compliance

    Agency Approvals: CB, CE, CUL, EAC, EN, TUV, UL

    Dimensions & Appearance

    Style:Enclosed
    Color:Silver
    Height:1.5 in.
    Width:3.8 in.
    Length:5.1 in.

    Operating conditions

    Minimum Operating Temperature:-25°C
    Maximum Operating Temperature:70°C

    Input

    Input Frequency:47 Hz to 63 Hz
    Input Voltage:88 VAC to 264 VAC
    Maximum Input Current:2 A

    Output

    Number of Outputs:1
    Output Current (Channel 1):1.6 A
    Output Voltage (Channel 1):48 VDC
    Output Connector Type:Screw Terminal Block
    Output Voltage:48 VDC
    Output Current:1.70 A

    Features

    PFC Function:No
    Minimum Isolation Voltage:3000V
    Efficiency:86%
    Power Rating:76.8 W
    ,
