300 Watt Single Output Medical Type

7.5 Volts @ 40 Amps

Features:

  • Universal AC input / Full range
  • Built-in active PFC function, PF>0.95
  • 86% efficiency
  • Withstand 300VAC surge input for 5 seconds
  • Protections: Short circuit / Overload / Over voltage / Over temperature
  • Built-in constant current limiting circuit
  • 1U low profile 41mm
  • Built-in cooling fan ON-OFF control
  • Built-in DC OK signal
  • Built in remote ON-OFF control
  • Standby [email protected]
  • Built-in remote sense function
  • No load power consumption<0.5W
  • 5 years warranty

Product Identification

Product Type:Medical Switching SMPS
Manufacturer Series:MSP-300

Compliance

Agency Approvals: CB, CE, CUL, EAC, EN, UL

Dimensions & Appearance

Style:Medical Enclosed
Color:Silver
Height:1.6 in.
Width:4.1 in.
Length:7.8 in.

Operating conditions

Minimum Operating Temperature:-40°C
Maximum Operating Temperature:70°C

Input

Input Frequency:47 Hz to 440 Hz
Input Voltage:85 VAC to 264 VAC
Maximum Input Current:4.5 A

Output

Number of Outputs:1
Output Voltage:7.5 VDC
Output Connector Type:Screw Terminal Block
Output Current:40 A

Features

PFC Function:Yes
Efficiency:86%
Power Rating:300 W
,
