75 mm x 75 mm x 30 mm Blower Fan 24 VDC Ball Bearing 13.8CFM 41.7dBA 12" Wires

Orion Fans

Jameco Part #:

Manufacturer #:

Primary datasheet

Product Price:

$21.950

In Stock: 0

Quantity	Unit Price	You Save	Discount
3+	$21.950	-	-
12+	$20.650	1.30	5.92%
48+	$19.350	2.60	11.85%

Features

Voltage Rating: 24 VDC
Height: 75 mm
Width: 75 mm
Depth: 30 mm
Air Flow (CFM): 13.8
Bearing: Ball
Current Rating: 200 mA
Power Rating: 4.8 W
Agency Approvals: UL, CUL
Noise (dBA): 41.7
Termination: 12" Wires
Product Type: 75 mm x 75 mm Blower Fan
Speed: 3400 rpm
Maximum Pressure: 0.56 in.
Motor Drive Type: Brushless DC, IC Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the blower fan is designed to operate up to 3400 rpm.
