7 Position FFC, FPC Connector Receptacle 0.100" (2.54mm) Free Hanging (In-Line)

Specifications

• Flat Flex Type: FFC, FPC
• Mounting Type: Free Hanging (In-Line)
• Connector/Contact Type: Receptacle
• Number of Positions: 7
• Pitch: 0.100" (2.54mm)
• Termination: IDC
• FFC, FCB Thickness: 0.33mm
• Contact Material: Copper Nickel Alloy
• Contact Finish: Tin
• Housing Material: Thermoplastic
• Voltage Rating: 500V
• Operating Temperature: -65°C ~ 105°C
• Material Flammability Rating: UL94 V-0
• Current Rating: 2A
• Contact Finish Thickness: 100µin (2.54µm)
• Housing Color: Blue
• Mating Cycles: 100
